| •Overall dimension 7500 x 3500 x 4500mm outer. |
| •Inner dimension 7300 x 3300 x 4400 mm. |
| •Lining of mineral wool thick 100 each side covered with GI perforated sheets of 0.8 mm. |
| •Mineral wool is covered with fire retardant tissue lining. |
| •nner perforated sheet of GI having thickness of 0.8 mm. |
| •Acoustic slab thickness 50 x 2 nos mm in FR grade 96kg/m3. density. •DGU Glasses for inspection window double layer. 6 mm thk •Opening doors single / two leaf swing type on the side of the enclosure. |
| •Lumen inside for proper visibility 600 Lux level on Philips / Syska LED. |
| •All the hardware in GI plated for inner application. |
| •All the external hardware is in SS 304 to prevent it from rust. •All the electrical Wiring & connectors Accessories are of STD make with proper routine in PVC casing. •Ladder frame , realing in 50 x 50 x 2 mm square tubes.. |
