| •Overhaul dimension 2500 x 2500 x 2500 mm outer (L.W.H). |
| •Inner dimension 2000 x 2000 x 2200 mm actual work space. |
| •Lining of mineral wool thick 100 each side. |
| •Acoustic slab thickness 100 mm in FR grade. |
| •Wood wool / poly board panels 15 mm @ 400kg density. |
| •Acoustic foam pyramid shape 150 x 150 x 150 mm @ 30 kg density. |
| •DGU Glasses for inspection window double layer. 25 mm. |
| •Opening doors single leaf Hinges type on the front side of the enclosure. |
| •All the input perimeters will display on the screen i.e. sound in dBa. • While testing rejected product will highlight and gave a siren while rejection. • Testing perimeters are editable for the setting of tolerances. • Inbuilt storage of one month in the system and easy to transfer through USB port. • Accuracy SOUND 2-3 % voltage 2 % current 1 % RPM 1 %. • MITSUBISHI Make 7’’ HMI for Operation of system. • Counting & failure reason for rejected of job , along with rejected count. •Cycle period is editable and extended to 12-120 sec. |
