| •Lining of acoustic foam thick 75 each side. |
| •Acoustic slab thickness 75 mm in FR grade. |
| • DGU Glasses for inspection window double layer. |
| •Opening doors single/ double leaf Hinges type on the front side of the enclosure along with louvers. |
| • Dimension of doors refer to GA submited • Fire proof tissue lining ( Fiber Glass). |
| •Temperature resistance up – to 100 oC. |
| •Foundation frame 75 mm “C” channel ISMC. |
| •Body 1.2 / 1.6 mm CARC powder coated is in metallic panels.. |
| •All the electrical components along with safety of MCB.. • Exhaust ventilation fan of 12 ‘’ * 2 nos for cross ventilation of internal heat removal.. |
